PoE Ethernet Switch 8 Port 10/100/1000T 2 Port 1000BASE SFP Auto-Sensing Switch
Power Over Ethernet Switch Advantages
► Supports external 1000Base SFP
► Support: Overcurrent, Shortcurrent, OverVOL, Power Limitation.
► Distinguish Active PD and Passive PD
► Sharing a total of 150W POE
Technical Indexes
| Ethernet & Fiber | |
| System Mode | Standard/VLAN Isolation |
| Switch Fabric | 20 Gbps |
| MAC address | 8K |
| Ethernet Port | 8 x 10/100/1000Mbps RJ45 Ethernet Ports |
| Optical Port | 2 x SFP 1000Base-FX |
| Electrical and Mechanical | |
| Input Power (AC/DC 2 power) | 48~57VDC or 100~265VAC 50/60Hz |
| Power Consumption | 20W Max. (PoE not in use) |
| 150W Max. (PoE in use) | |
| PoE | |
| Standard | IEEE802.3af/at |
| Port | RJ45 Port1~Port4 |
| Max. Power per port | 30W Max per port (Alternative B mode) |
| PoE Output Auto-sensing | Support both Active and Passive PD without setting |
| PoE Interfaces | PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 8-) |
| Function | Support Overcurrent, Shortcurrent, OverVOL, UnderVOL, Power Limitation, Safe Function HiPower PD star BOOT, After Boot |
Overview
LNK-A208GP-SFP product is an Ethernet POE switch which provides 4 port 10/100/1000Base-TX + 2x1000Base-FX SFP port. Eight Gigabit RJ45 ports offer different power output options: auto-sensing IEEE 802.3af/at POE/POE+ and 24V passive POE, and two SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.
Ordering Information
| Model | Description |
| LNK-A208GP-SFP | Auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE Switch: 8-Port 10/100/1000BASE-T + 2-Port 1000BASE SFP |
| SFP Options | ► SFP option. Please select your SFP on our SFP Options Page |
| ► SFP module is to be purchased separately. | |
| Mounting Options | ► Wall-mount and desk/shelf mounting |
